LG 110UM5K 110″ UM5K Series 4K UHD Digital Signage

A large display is installed on a shopping mall’s interior wall, and the display’s screen is showing advertisements clearly and vibrantly.

UHD Large Screen Signage Display with LG webOS Platform

* All images in this page are for illustrative purposes only.

Super High Resolution

Delivering immersive viewing experience by 4 times higher definition picture quality than FHD.

The difference comparing at a glance is shown in Ultra HD quality, which is four times higher than Full HD.

Adequate Brightness Level

The UM5K series boasts an adequate brightness level of 500 cd/m² for indoor displays, effectively showcasing content and capturing the public’s attention. This makes it an adequate display solution for marketing purposes in various settings, including meeting rooms, airports, retail outlets, and shopping malls.

* Actual images available may differ from the example images shown.

UM5K has a brightness of 500 nits, so it is clearly visible, even under strong light.

High-Performance with webOS

LG webOS platform enhances user convenience with intuitive GUI and simple app development tools.

A number of tasks can be done at the same time with the intuitive GUI.

Built-in Speaker

Contents will be enriched with sound effects from built-in speakers, without the need for purchasing or installing external speakers.

* Internal Built-in Speaker Support (L/R max 10 W)

One signage on the wall has a built-in speaker which renders rich audio.

The bezel size of UM5K is 17mm. And the depth of the UM5K 98" is 79.5mm, and 110" is 99mm.

Slim Design

Being slim, a closer installation to the wall is advised. Additionally, this increases the screen’s immersive experience and provides a sophisticated design, improving the installed-space’s décor.

Compatible with AV Control System

The UM5K series has supported Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control*, boosting business management efficiency.

* Network based control

The AV control system helps users control the UM5K

Cafe managers are creating menus that will be displayed on the display installed on the cafe wall using content management software.

SuperSign Solutions

SuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.

Panel Specifications

Screen Size: 110″
Panel Technology: ADS
Backlight Type: Direct
Aspect Ratio: 16:9
Native Resolution: 3,840 x 2,160 (4K UHD)
Refresh Rate: 120 Hz
Brightness (Typical): 500 nits
Contrast Ratio: 1,200:1
Dynamic Contrast Ratio: 1,000,000:1
Color Gamut: DCI-P3 88%↑
Viewing Angle: 178° (Horizontal) x 178° (Vertical)
Color Depth: 1.07 Billion Colors (8 bits + FRC)
Response Time: 8 ms (G to G)
Surface Treatment (Haze): 1%
Lifetime: 50,000 hours (Typical)
Operation Hours: 16 hours / 7 days
Portrait / Landscape: No / Yes

Mechanical Specifications

Bezel Color: Black
Bezel Width: 17 mm (Even Bezel)
Weight (Head): 80 kg
Packed Weight: 110 kg
Monitor Dimensions (W × H × D): 2,474 x 1,408 x 99 mm
Carton Dimensions (W × H × D): 2,680 x 1,730 x 320 mm
Handle: Yes
VESA Mount Interface: 1,500 x 600 mm

Key Features (Hardware)

Internal Memory: 16 GB
Wi-Fi: Built-in Wi-Fi
Sensors:
- Temperature Sensor
- Auto Brightness Sensor
- Acceleration (Gyro) Sensor
Local Key Operation: Yes
Power Indicator: Yes

Key Features (Software)

webOS Version: webOS 6.0
Software Features:
- Local Contents Scheduling
- Group Manager
- USB Plug & Play
- Failover
- Booting Logo Image
- No Signal Image
- Local Network Sync
- Picture-in-Picture (PIP)
- Picture-by-Picture (PBP) (Up to 4 screens)
- Screen Share
- Video Tag (Up to 4)
- Play via URL
- Tile Mode Setting (Max. 15×15)
- Setting Data Cloning
- SNMP
- ISM Method
- Auto Set ID
- Status Mailing
- Control Manager
- Cisco Certification
- Crestron Inside
- Smart Energy Saving
- Power Management (PM) Mode
- Wake on LAN
- Network Ready
- Beacon
- HDMI-CEC
- SI Server Setting
- webRTC
- Pro:Idiom

Environmental Conditions

Operating Temperature: 0°C to 40°C
Operating Humidity: 10% to 80%

Power Specifications

Power Supply: AC 100-240 V~, 50/60 Hz
Power Type: Built-In Power
Power Consumption:
- Typical: 440 W
- Max: 570 W
- Smart Energy Saving (70%): 308 W
- DPM (Display Power Management): 0.5 W
- Power Off: 0.5 W
BTU (British Thermal Unit):
- Typical: 1,501 BTU/Hr
- Max: 1,945 BTU/Hr

OPS Compatibility

OPS Type Compatible: No
OPS Power Built-In: No

Software Compatibility

Supported Software:
- SuperSign CMS
- SuperSign Control+
- SuperSign WB
- SuperSign Cloud
- Mobile CMS
- LG ConnectedCare

Connectivity

Input:
- HDMI (3 ports) (HDMI1/2: HDCP 2.2/1.4, HDMI 3)
- DP (HDCP 2.2/1.3)
- DVI-D (HDCP 1.4)
- Audio In
- RS-232C (4 Pin Phone-jack)
- RJ45 (LAN)
- IR In
- USB 2.0 Type A
Output:
- HDMI Out
- Audio Out
- RS-232C Out (4 Pin Phone-jack)
- Daisy Chain (Input: HDMI, DP, DVI / Output: HDMI)

Sound

Speakers: Yes (10W x 2)

Language Support

Languages:
- English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Traditional), Portuguese (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese (Europe), Dutch, Czech, Greek, Turkish, Arabic, Polish

Certifications

Safety: CB / NRTL
EMC: FCC Class “A” / CE / KC
ErP: Yes (New ErP)

Accessories

Included:
- Remote Controller (with 2 batteries)
- Power Cord
- Quick Start Guide (QSG)
- IR/Light Sensor Receiver
- Regulation Book
- Phone to RS232C Gender
Optional: No
