LG 86UL5Q-M 86″ 4K UHD Signage

Tech Specifications:

Panel

• Screen Size 86″
• Panel Technology ADS
• Back Light Type Direct
• Aspect Ratio 16:9
• Native Resolution 3,840 x 2,160 (4K UHD)
• Refresh Rate 60 Hz
• Brightness (Typ.) 500 nits
• Contrast Ratio 1,200:1
• Dynamic CR 1,000,000 : 1
• Color gamut DCI 80%
• Viewing Angle (H x V) 178 × 178
• Color Depth 1.07 Billion Colors (Advanced 10 bit)
• Response Time 8ms (G to G)
• Surface Treatment (Haze) 1%
• Life Time (Min.) 50,000 Hrs
• Operation Hours (Hours / Days) 24 / 7
• Portrait / Landscape Yes / Yes

Mechanical Specification

• Bezel Color Black
• Bezel Width 12.9 mm (Even)
• Weight (Head) 31.8 kg
• Packed Weight 42.6 kg
• Monitor Dimensions (W × H × D) 1,926.6 × 1,098 × 60 mm
• Carton Dimensions (W × H × D) 2,080 × 1,255 × 220 mm
• VESA™ Standard Mount Interface 600 × 400 mm

Environment Conditions

• Operation Temperature 0°C to 40°C (Portrait Scene : 0°C to 35°C)
• Operation Humidity 10 % to 80 %

Power

• Power Supply AC 100-240 V ~, 50/60 Hz
• Power Type Built-In Power

Power Consumption

• Typ./Max. 220 W / 330 W
• Smart Energy Saving (70%) 154 W
• DPM 0.5 W
• Power off 0.5 W
• BTU (British Thermal Unit) 750.671B TU/Hr (Typ.), 1126.007 BTU/Hr (Max.)

Standard (Certification)

• Safety CB
• EMC FCC Class “B” / CE
• ePEAT(US only) Yes
• ErP / Energy Star N/A / Yes
