Samsung LH115QHFEBGXXS 115″ QH115FX UHD Signage QHFX

Key Features:

• Supersized Screen
• Portrait Installation
• Anti-Glare
• 24/7 operation

Technical Specifications:

Display:

• Diagonal Size: 115″
• Panel Type: VA
• Resolution: 3,840 x 2,160
• Pixel Pitch (HxV): 0.630 x 0.630 mm
• Brightness (Typ): 1000 nit
• Contrast Ratio: 5500:1
• Viewing Angle (H/V): 178/178
• Response Time: 6.5ms
• Colour Gamut: 93% (DCI-P3)
• Glass Haze: 25%
• H-Scanning Frequency: 15 – 135 kHz
• Maximum Pixel Frequency: 1.188 GHz
• V-Scanning Frequency: 24 – 120 Hz
• Contrast Ratio (Dynamic): Mega
• Operation Time Support: 24/7

Connectivity:

• HDMI In: 3
• DP In: 1
• Version of HDMI: 2.1
• Version of DP: 1.4
• Version of HDCP: 2.2
• USB: 2 x USB-A
• IR In: Yes
• Audio In: No
• Audio Out: Stereo Mini Jack
• RS232 In: Yes
• RS232 Out: Yes
• RJ45 In: Yes
• WiFi: Yes
• Bluetooth®: Yes

Power:

• Power Supply: AC100-240V 50/60Hz
• Power Consumption (On Mode): 836 W
• Power Consumption (Sleep Mode): 0.5 W

Dimensions:

• Set Dimension (WxHxD): 2565.2 x 1467.6 x 34.1 mm
• Package Dimension (WxHxD): 2765.0 x 1652.0 x 250.0 mm

Weight:

• Set Weight: 83.7 kg
• Package Weight: 133.6 kg

Operation Conditions:

• Temperature: 0℃~ 40℃
• Humidity: 20 ~ 95%, non-condensing

Mechanical Specification:

• VESA Mount: 1000 x 600 mm
• Bezel Width: 3 Bezel-less
• Bezel Color: TITAN BLACK
• Frame Material: Non-Glossy

Optional Feature

• Mount: Slim Fit Wall-mount (Inbox)
• Stand: Yes(Inbox)

SoC:

• OS Version: Tizen 8.0
• Flash Memory Size: 16GB

Certification and Compliance:

• EMC: Class A
• Safety: 60950-1, 62368-1
