Samsung LH85QBCEBGCXXS QB85C 85″ QBC/QBB series | 16/7, 350nit, MagicInfo Built- In

  • Diagonal Size: 85″
  • Panel Type: VA
  • Resolution: 3,840 x 2,160
  • Pixel Pitch (HxV): 0.487×0.487mm
Share
Contact Now
Overview Specification

Brightness (Typ): 350 nit

Contrast Ratio: 4,000:1

Viewing Angle (H/V): 178/178

Response Time: 10ms

Colour Gamut: 72% (NTSC)

Glass Haze: 2%

H-Scanning Frequency: 30~81kHz

Maximum Pixel Frequency: 594MHz

V-Scanning Frequency: 48~75Hz

Contrast Ratio (Dynamic): Mega

Operation Time Support: 16/7

Display

  • Diagonal Size: 85″
  • Panel Type: VA
  • Resolution: 3,840 x 2,160
  • Pixel Pitch (HxV): 0.487×0.487mm
  • Brightness (Typ): 350 nit
  • Contrast Ratio: 4,000:1
  • Viewing Angle (H/V): 178/178
  • Response Time: 10ms
  • Colour Gamut: 72% (NTSC)
  • Glass Haze: 2%
  • H-Scanning Frequency: 30~81kHz
  • Maximum Pixel Frequency: 594MHz
  • V-Scanning Frequency: 48~75Hz
  • Contrast Ratio (Dynamic): Mega
  • Operation Time Support: 16/7

Connectivity

  • HDMI In: 3
  • DP In: No
  • Version of HDMI: 2
  • Version of DP: No
  • Version of HDCP: 2.2
  • USB: 2
  • IR In: Yes
  • Audio In: No
  • Audio Out: Stereo Mini Jack
  • RS232 In: Yes
  • RS232 Out: Yes
  • RJ45 In: Yes
  • WiFi: Yes
  • Bluetooth®: Yes

Power

  • Power Supply: AC100-240V 50/60Hz
  • Power Consumption (On Mode): 231 W
  • Power Consumption (Sleep Mode): 0.5 W

Dimension

  • Set Dimension (WxHxD): 1904.3 x 1085.3 x 28.5 mm
  • Package Dimension (WxHxD): 2077 x 1222 x 210 mm

Weight

  • Set Weight: 41.9 kg
  • Package Weight: 53.9 kg
