Epson EB-W55 WXGA 3LCD Projector

Overview:

• WXGA Resolution
  Displaying clear and crisp visuals thanks to its WXGA resolution, the Epson EB-W55’s high resolution is able to support vivid display on large screen sizes
• Easy Maintenance and Longer Lamp Life
  A long lamp life reduces maintenance and costs. The lamp will last up to 12,000 hours in ECO mode. Cut down on the frequency of lamp replacements, saving you time and money, and lowering the total cost of ownership.
• Various Interfaces
  Epson business projectors support a wide range of connectivity options. Works with various HDMI capable equipments as well as your smart devices via the wireless function.
• Flexible Display Size
  Why settle for smaller screens when you can have more 120″ and even up to 300″? EB-W55 supports a variety of aspect ratio and display size up to 320″ diagonal.
• Split Screen Capability
  Use the projector to show 2 different images from 2 different devices at the same time using split screen function. Example, you can now show your presentation on one side while seeing the video on the other side.
• USB-A Power Supply
  Connect external streaming device such as Epson ELPAP12 Android TV Dongle to turn your projector to be smart display for you to access various entertainment contents such as Youtube, Internet Browser, etc.
• Advanced Wireless Presentation
  Use with Epson iProjection software on your PC/Laptop for advanced wireless presentation features such as screen freeze, moderator function for collaborations and displaying up to 4 different screen on 1 projector.

Specifications:

Brightness1:

• White Light Output (Normal/Eco): 4,000 lm / 2,600 lm
• Colour Light Output: 4,000 lm

Projection Lens:

• Type: Optical Zoom (Manual) / Focus (Manual)
• Focal Length: 16.9-2.28mm
• F-number: 1.49-1.72
• Zoom: 1.0-1.2
• Throw Ratio Range: 1.30 – 1.59

Screen Size (Projected Distance):

• Zoom : Wide: 31” – 304” [0.88 – 8.88 m]
• Zoom : Tele: 31” – 304” [1.43 – 14.29 m]

Geometric Correction:

• Vertical/Horizontal Keystone: ±30° / ±30°

Operating Altitude:

• Operating Altitude: 0 – 3,000 m <0 – 9,843 ft> ( over 1,500m / 4,921ft: with high altitude mode)

Adjustment Functions:

• Scene Adaptive Gamma: Yes

Dimension Excluding Feet:

• Dimension Excluding Feet (W x D x H): 302 x 234 x 87 mm
• Weight Approx. 2.6kg

General Projectors:

• Interfaces:
  • Digital Input: HDMI Type A : 2 (HDCP 1.4)
  • Audio Output: Stereo Mini : 1
  • USB Input: USB Type A : 1 (480Mbps for PC Free, Firmware update, Copy OSD Settings or 5V/2A Power Supply)
  • USB Type B : 1 (For Firmware Update, Copy OSD Settings)

Main Parts Specification:

• LCD: Size : 0.62” (C2 Fine) Driving Method : Poly-silicon TFT active matrix Pixel Number : 2,073,600 dots (1920 x 1080) x 3 Native Resolution : Full HD Aspect Ratio 16:9 Pixel Arrangement : Cross stripe Contrast Ratio:16,000:1
• Lamp: Lamp Type : 230 W UHE
• Life (Normal / Eco) : 5,500 hours / 12,000 hours
• Light Source: Lamp

Start Up Period:

• Start Up Period: Less than 7 seconds (Epson Logo); Warm-up Period: 30 seconds
• Direct Power On / Off:
• Direct Power On / Off: Yes
  Power Consumption (220-240V): Lamp (Normal / Extended): Normal : 332 W; Extended : 231 W

Colour Mode:

• Colour Mode: Blackboard, Cinema, Dynamic, Presentation, sRGB

Connectivity Projector:

• Standard Connectivity:
  • Network: Wireless LAN : Built-in
  • Digital Input: HDMI Type A : 2 (HDCP 1.4)
  • USB Input: USB Type A : 1 (480Mbps for PC Free, Firmware Update, Copy OSD Settings or 5V/2A Power Supply)
  • USB Type B : 1 (For Firmware Update, Copy OSD Settings)
